TLM Audio is proud to present our very own take
on the Mutable Instruments Grids.

TRIGS is a performance oriented and size optimized topographic drum sequencer based on the classic Mutable Instruments Grids module.
It is built, calibrated and tested with the highest quality standards.
The Module is manufactured and assembled in germany.

Features
Clocking
Internal clock with a 40 to 240 BPM range.
Beat indicator / Tap tempo button (reconfigurable as a reset button).
External clock input, with selectable resolution (24, 8 or 4 ppqn).
Pattern reset trigger input.
Drum pattern generator
Based on a compressed representations of drum patterns and their variations.
X/Y (pattern selection) knobs with CV inputs.
Pattern complexity/density knobs for channels 1, 2, 3, with CV inputs.
Pattern randomization knob with CV input (reconfigurable as a swing control for the internal clock).
3 output channels (BD, SD, and HH/percussion).
3 additional outputs, configurable as Accent/Clock/Reset or per-channel accent.
Outputs can be either triggers or gates.
Specifications
Input impedances: 100k.
CV acquisition: 8-bit, 1kHz.
Output level: +5V.
Clock resolution and processing latency: 120µs.
Worst case jitter < 0.5% at 120 BPM.
